IAG Fire-Lock 2.5L Subaru Head Gaskets (1 Pair w/ Fire-Lock Rings) for EJ25 / EJ257, 100mm, .051", for 14mm Head Studs

IAG Fire-Lock 2.5L Subaru Head Gaskets (1 Pair w/ Fire-Lock Rings) for EJ25 / EJ257, 100mm, .051", for 14mm Head Studs

$299.99

IAG FIRE-LOCK 2.5L SUBARU EJ25 HEAD GASKETS


IAG Fire-Lock Head Gaskets for Subaru 2.5L EJ25 Engines

HIGH HORSEPOWER & HIGH BOOST

Our proprietary "Fire-Lock™" Head gasket system has been proven in our record-setting race cars to be the strongest Subaru head gasket system ever produced. To achieve these results, our engineers separated the combustion chamber sealing from the fluid sealing aspects of the head gaskets. These gaskets have been tested in excess of 1000 horsepower.

PRECISION MACHINING

This solution is loosely derived from diesel technology where a counterbore step is machined around each cylinder bore allowing specially sized fire rings to drop into the machined area and head gasket bores. The shims are designed to create a compression seal once the heads are installed and torqued into place. When producing the IAG 950 and 1150 closed deck cases, our machinists carefully machine a recess at the top of each cylinder to accept the "Fire-Lock™" ring. With the ring locked in place, it stands proud above the deck, providing a superior seal. IAG fire rings are manufactured to a very strict tolerance from a proprietary alloy and are then put through a heat treatment process. 14mm Head Studs are required for Fire-Lock™ Gaskets

IAG Fire-Lock Ring
IAG Fire-Lock Gaskets for Subaru

PROPER SEALING

The gaskets are manufactured from an asbestos-free composite raw material and feature silicone-based beading applied to critical areas to improve sealing around all water and oil passages. The separate gasket bodies take care of sealing oil and coolant passages, keeping them out of the combustion chamber. The combination of the alloy compression shims and gaskets assures maximum sealing for a Subaru EJ25 turbocharged engine. The IAG 950 & 1150 Cases are also machined to accept 14mm Head studs (Not Included) to ensure proper head gasket seal.

*The IAG Fire-Lock™ gaskets require machine work for installation.

What's Inside:

  • Product Name: IAG Fire-Lock™ 2.5L Subaru Head Gaskets (1 Pair w/ Fire-Lock™ Rings)
  • Part Number: IAG-ENG-1741
  • Gasket Material: Composite with Silicone Beading
  • Ring Material: IAG-Spec Alloy
  • Thickness: .051"
  • Bore: 100mm
  • Head Stud Size: 14mm (*IAG 14mm Head Studs Required for use)
  • Package Includes: 2 x Fire-Lock™ Head Gaskets, 4 x Fire-Lock™ Rings
  • Fitment: Subaru EJ25, EJ257 Closed Deck Cases *Required Machining

Installation Instructions:

Install Notes:
1. If a block or cylinder head was previously o-ringed the groove must be filled and resurfaced before using this type of gasket.
2. These gaskets require IAG ARP 14mm head studs to achieve the required torque necessary for proper installation.
3. Due to the required torque, any block that was previously honed will need to go to the next size overbore.
4. Future servicing will require cylinder head resurfacing due to an imprint left from the Fire-Lock™ rings.





Model Year & Fitment


  • 2002 Subaru WRX w/ EJ25
  • 2003 Subaru WRX w/ EJ25
  • 2004 Subaru WRX w/ EJ25
  • 2005 Subaru WRX w/ EJ25
  • 2006 Subaru WRX
  • 2007 Subaru WRX
  • 2008 Subaru WRX
  • 2009 Subaru WRX
  • 2010 Subaru WRX
  • 2011 Subaru WRX
  • 2012 Subaru WRX
  • 2013 Subaru WRX
  • 2014 Subaru WRX
  • 2004 Subaru STI
  • 2005 Subaru STI
  • 2006 Subaru STI
  • 2007 Subaru STI
  • 2008 Subaru STI
  • 2009 Subaru STI
  • 2010 Subaru STI
  • 2011 Subaru STI
  • 2012 Subaru STI
  • 2013 Subaru STI
  • 2014 Subaru STI
  • 2015 Subaru STI
  • 2016 Subaru STI
  • 2017 Subaru STI
  • 2018 Subaru STI
  • 2019 Subaru STI
  • 2020 Subaru STI
  • 2021 Subaru STI
  • 2005 Subaru Legacy GT
  • 2006 Subaru Legacy GT
  • 2007 Subaru Legacy GT
  • 2008 Subaru Legacy GT
  • 2009 Subaru Legacy GT
  • 2004 Subaru Forester XT
  • 2005 Subaru Forester XT
  • 2006 Subaru Forester XT
  • 2007 Subaru Forester XT
  • 2008 Subaru Forester XT
  • 2009 Subaru Forester XT
  • 2010 Subaru Forester XT
  • 2011 Subaru Forester XT
  • 2012 Subaru Forester XT
  • 2013 Subaru Forester XT
